Brotherhobby T1 Tornado 1407 Brushless FPV Motor – 3600KV

Description

Features:
Suitable for 130 150 frame kit and more powerful
Rotor: 1.5mm N52H (arc magnets)
Base casing: Al 7075
Bell cap:Al 7075
Small size and light weight

Specification:
Model: Tornado T1
Item Name: 1407 3600KV 4S Racing Edition Brushless Motor
RPM/V: 3600KV
Thread: CW
Stator Diameter: 14mm
Stator Height: 7mm
Shaft Diameter: 2mm
Motor Diameter: 18.6mm
Motor Height: 30.6mm
Prop Adapter Shaft Thread: M5
Input voltage: 3S-4S (12.6 – 16.8v)
Bolt Pattern: M2 (12mm)
Weight: 15.5g
Wire AWG: 26AWG
