Summary :
FRsky D4R-II Receiver is a 4 channel (PWM) or 8 channel (CPPM) 2.4Ghz receiver which uses the FRsky ACCST technology (Advanced Continuous Channel Shifting Technology) to ensure rock solid signal to your aircraft.
If you need to use more than 4 Channels with this receiver you simply need to add a jumper (included) across CH3 and CH4 and the FRsky D4R-II receiver will output an 8 CH CPPM signal over the CH1 connection, and the RSSI over CH 2.
The D4R-II’s data port allows you to connect a sensor hub so you can connect GPS, Variometer, temperature, RPM and all of the other great FrSky sensors. It also has 2 full length detachable antennas. They managed to squeeze all this into a package just a little larger then the D4FR.
Compatible with FrSky two-way telemetry modules: DFT, DJT, DHT, DHT-U
Features :
2 full length antennas (replaceable)
RSSI (PWM) and CPPM output.
Lighter weight and physically smaller than D8R-II & D6FR
Integrated warning alarm for low voltage, poor reception, etc.
One external analog telemetry port and one digital data-stream port (Connects to FrSky Sensor Hub FSH-01).
Specs :
Number of Channels: 4
Operating Voltage Range: 3.5V~10V
Operating Current: 60mA
Operating Range: Full Range (>1.5km)
Dimension: 40×22.5x6mm
Weight: 5.8g
