Description
Features
High performance microprocessor, best compatibility with all kinds of motors, highest driving efficiency.
Optimized for multi-rotor aircraft.
Smooth, linear, quick and precise throttle response.
Multiple protection features: Low-voltage cut-off protection / Over-heat protection / Throttle signal loss protection.
The firmware of the ESC can be updated through the built-in USB adapter in the Professional LCD Program Box.
User programmable.
Specification
Output: Continuous 30A, burst 40A up to 10 seconds.
Input Voltage: 2-6 cells lithium battery or 5-18 cells NiMH battery.
BEC: Not available.
Refresh rate of the throttle signal: 50Hz to 432Hz.
Max Speed: 210000rpm for 2 Poles BLM, 70000rpm for 6 poles BLM, 35000rpm for 12 poles BLM.
(BLM = BrushLess Motor)
Size: 55mm (L) * 25mm (W) * 12mm (H).
Weight: 31g
