Description
– Waterproof and dust-proof for all-weather races.
(Note: please uninstall the cooling fan before using this ESC in water; Clean and dry it soon after the use for avoiding the connectors get rusty.)
– External programming port, easy to connect to the Program Card when setting the ESC.
– Proportional brake with 4 steps of maximum brake force adjustment and 8 steps of drag brake force adjustment.
– 9 steps of acceleration (/punch) adjustment from “soft” to “Very aggressive” to fit for different kinds of models, tires and tracks.
– Multiple protections: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor lock-up protection.
– One-button (the “SET” button on the ESC) to set the ESC, and easy to reset all parameters to the factory default settings.
– Compatible with the optional device —- the portable Digital LED Program Card, especially convenient for outdoor use.
Motor Limit :
For 2S Lipo or 6 cells NiMH:
1. On-road: 2435-size or smaller motor with the KV<8000
2. Off-road/Buggy/Monster: 2435-size or smaller motor with the KV<5000
For 3S Lipo or 9 cells NiMH:
1. On-road: 2435-size or smaller motor with the KV<5500
2. Off-road/Buggy/Monster: 2435-size or smaller motor with the KV<3500
