Description
Package Includes
1x Cicada 30A 4in1 ESC
1x bag of mounting spacers with screws
1x cable set (to connect to FC)
Summary
These have the BB2 chip and will support DSHOT without modification.
Introducing the state-of-the-art in multirotor 4-in-1 ESCs. Been dreaming of that compact installation on a standardized stack or extra protection for your ESCs? 40% lighter than a typical set of 4 ESCs, this is the answer for a light race frame with thin arms or tubular arms.
This is not your old-school 4-in-1 ESC because of its ability to support 6S Lipo input, the 6 layer PCB design, and a 3 oz PCB pour. It is really a 4-in-1 ready for a race environment. The design uses hardware PWM for ultra smooth motor response. Oneshot 125, Oneshot42 and Multishot are auto-detected. Dshot 150, 300 and 600 are supported without making any modifications (input caps have been removed). Please note, these are the newest version with the BB2 processor operating at 48MHz.
Specification
Continuous Current: 30A
Burst Current (10s): 35A
Battery: 2-6Lipo
BEC : No
Dimensions: 36 x 36mm
Mounting: 30.5 x 30.5mm center to center
Weight: 25g
