Description

16 Amp 2×13 Position Terminal Block Distribution Module for AC DC

• 16Amp 48V 2×13 position screw terminal block distribution module. Support for multiple module extension connections.
• Rated current 16 Amp(total input or output), Maximum voltage 48V
• A / B terminal blocks, Pitch 7.5mm/0.295″, Wire range 26AWG ~ 12AWG / 2.5mm square. Rated current 16Amp. Strip length 7mm. Screws – M3,steel, Cr3+ Zn plated. Pin header and Cage – Brass.
• A1~B6 / A7~B12 terminal blocks, Pitch 5.0mm/0.197″, Wire range 26AWG ~ 12AWG / 2.5mm square. Rated current 16Amp. Strip length 7mm. Screws – M3,steel, Cr3+ Zn plated. Pin header and Cage – Brass.
• CE certified terminal blocks, FR-4 glass fiber PCB.
