Compact 600TVL FPV camera featuring Sony’s 1/3-inch HAD CCD imaging sensor for high-resolution, low-light performance

Description

This is the Sony Super HAD CCD 600TVL FPV Sensitive Camera, with an included 2.8mm lens. This professional 600TVL IR Sensitive / Blocked FPV camera uses 1/3 inch Sony Super HAD CCD technology to produce high quality crisp images, even in low light conditions! The camera also features Nextchip 2040 DSP, with a minimum illumination up to 0.01Lux. This classic FPV camera is very popular due to it’s high performance to low cost ratio.

Features :

High resolution of 600TVL (color), 650TVL (black&white)

1/3″ SONY SUPER HAD II CCD

Nextchip 2040 DSP

Mirror function

8 privacy areas

0.01Lux Low illumination

Powerful OSD menu

D-WDR (Wide Dynamic Range)

2D-DNR (Digital Noise Reduction)

Low Power Consumption

Suitable for FPV

Specifications :

Model: CC1333

CCD: 1/3” Sony SUPER HAD II CCD

Pixel: PAL: 752(H) ×582(V); NTSC: 768(H)×494(V)

TV System: PAL or NTSC color system(based on country)

Resolution: 600TVL

Synchronization: Power synchronize / internal synchronize

Shutter Speed (CCD IRIS): PAL: 1/50~1/100000 sec; NTSC: 1/60~1/100000 sec

Noise: > 60 (AGC OFF)

Video Out: 1.2Vp-p,75ohm, synchronize

Horizontal Resolution: Color 600TVL, B&W (ICR shift) 650TVL

Min. Illumination: Color: 0.01Lux

Auto Gain: Off/Low/Mid/High

Back Light Compensation (BLC): Off /Back light compensation/ Strong light suppression

Private shading (PRIVACY): 1~8 private shading area

Motion Detection (MD): On/ Off (Multi level sensitivity settable)

Auto White Balance: Manual / Auto / Auto track

Mirror: Horizontal Mirror optional

Negative: Positive / Negative optional

Edge Brightness Compensation: Support

Car Reverse Line: Support

Anti-exposure: On/ Off

IR Wavelength: 850nm

IR On & Color to B&W Synchronize: Support (optional)

IR Image Optimize: Avoid center object expose

DNR: 2DNR

Day / Night Shift: Auto/ Color/ B&W/ External control (can set start and end position)

Day / Night Shift time: 2~63 shift time optional

Menu (OSD): English menu

White Dot Repair: Support

Image Adjustment: Support

Camera Title: Support

Auto IRIS: Integrated auto IRIS driver

Power Requirement: DC12V

Working Temperature: -10 C ~ +50 C

Working Humidity: 20~80%

Storage Temperature: -40 C ~ +60 C

Storage Humidity: 20~95%

Dimensions(mm): 38X38(W*L)

Power Consumption: 80mA
